Piston Speed Range 50 To 500 Mm/s Automation Cylinder for Maximum Operating Pressure 1.0 MPa in Industrial Applications

Product Description:

The SMC CQ2A Series ultra-compact cylinders deliver high-precision linear motion in space-constrained applications. Featuring a 12mm bore size with stroke options of 5/10/15/20/25/30/35/40/45/50mm , these double-acting single-rod cylinders combine 30% shorter length than standard cylinders with robust performance.

Constructed from aerospace-grade aluminum with hard anodization, they operate at 0.05-1.0MPa (7-145 psi) to generate 90N maximum thrust . Pre-lubricated seals enable maintenance-free operation while integrated magnetic fields support sensor mounting.

Compatible with SMC's modular accessory system including guides, valves, and mounting brackets.

Features:

1. Space-Optimized Design
Ultra-Compact: 24mm width, 40% shorter than ISO cylinders (e.g., 82mm @50mm stroke)
Lightweight: Topology-optimized aluminum body (0.15kg @50mm stroke)
Modular Integration: Direct mounting with MXS guides/VQ valves

2. Precision Performance
Balanced Thrust: 90N±3% bidirectional force @1.0MPa
High Speed: 500mm/s operation, 0.15s response time @50mm stroke
Adjustable Cushioning: Optional hydraulic damper (0.043J absorption)

3. Enhanced Durability
Wide Temp. Option: -XB6 seals for -40~150°C (-40~302°F) operation
Corrosion Resistance: -XC6 stainless steel kit (SUS304 rod)
IP65 Protection: -XC4 dual wipers for dust/dirt environments

4. Smart Mounting
4-Side Sensor Slots: Compatible with D-M9N sensors (Φ3.5mm slot)
8 Mounting Styles: Pre-loaded screws for A/L/D-type configurations
Stroke Adjustment: ±5mm travel modification with -XC8 module

5. Advanced Engineering
Hard Anodized Bore: 25μm coating, 3× wear resistance
Hard Chrome Plated Rod: 0.02mm thickness, μ≤0.15 friction coefficient
Zero-Leakage Seals: X271 FKM compound, <0.1mL/min leakage @0.5MPa

Applications:

Diagnostic Sample Transfer:
35-50mm stroke variants with -XC6 stainless steel kits handle biological samples in analyzers, preventing contamination in FDA-compliant environments.

Reagent Dispensing:
Low-pressure operation (0.05MPa) achieves 0.1mL fluid dosing accuracy in IVD instruments using 10mm stroke units.

Compact Automation Cells
Optical Inspection:
40mm stroke cylinders position AOI cameras at 50-200mm/s adjustable speeds, minimizing vibration during high-magnification imaging.

Robotic End-Effectors:
Integrated with collaborative robots for lightweight part insertion (25mm stroke, M3 rod threads) under 0.5s cycle times.

Packaging Machinery
High-Speed Cutting:
50mm stroke models actuate blades in film-sealing systems, completing cuts in 0.2s at 1.0MPa with hydraulic cushioning for shock reduction.

Label Alignment:
15mm stroke versions with -DZ mounting ears correct label position deviations ≤0.3mm in pharmaceutical blister packaging lines.

Case Study:
A medical device manufacturer reduced machine thickness by 42% using CQ2A12-30DMZ with 4-side sensors, cutting downtime 70% in cartridge loading systems.
